Configure DirectAccess with OTP Authentication

Introduction

DirectAccess in Windows Server 2012 R2 provides significantly improved authentication over traditional client-based VPN solutions. When configured to use certificate authentication (a recommended best practice) the DirectAccess client is authenticated using its machine certificate and its Active Directory computer account. Once the client machine has been authenticated, the user is also authenticated via Kerberos against a live domain controller over the existing DirectAccess connection. These multiple authentication steps provide a high level of assurance for DirectAccess-connected clients. If that’s not enough to meet your needs, additional strong user authentication is supported using dynamic One-Time Passwords (OTP).

Drawbacks for DirectAccess with OTP

While OTP does provide an additional level of assurance, it does come with a few drawbacks. OTP adds additional complexity and makes troubleshooting more difficult. OTP cannot be configured with force tunneling; the two security features are mutually exclusive. DirectAccess OTP does not support RADIUS challenge-response. For Windows 7 clients, the DirectAccess Connectivity Assistant (DCA) v2.0 must be deployed. In addition, enabling OTP with DirectAccess disables the use of null cipher suites for IP-HTTPS. This can potentially have a negative effect on performance and scalability (more details here). Also, OTP fundamentally breaks the seamless and transparent nature of DirectAccess.

Configuring DirectAccess OTP

OTP for DirectAccess makes use of short-lived certificates for user authentication. Thus, enabling OTP for DirectAccess requires making changes to the internal Public Key Infrastructure (PKI). DirectAccess in Windows Server 2012 R2 can be configured to use the same Certificate Authority (CA) that is used to issue computer certificates to the DirectAccess clients and servers. This differs from DirectAccess with Forefront Unified Access Gateway (UAG) 2010, where a separate, dedicated CA was required.

To configure DirectAccess OTP, follow the instructions below.

OTP Certificate Request Signing Template

Open the Certification Authority management console, right-click Certificate Templates, and then choose Manage. Alternatively you can enter certtmpl.msc in the Start/Run box or search from the Windows Start menu. Right-click the Computer template and choose Duplicate Template. On the Compatibility tab, select Windows Server 2012 R2 for the Certification Authority and Windows 8.1/Windows Server 2012 R2 for the Certificate recipient.

Configure DirectAccess with OTP Authentication

Select the General tab and provide a descriptive name for the Template Display Name. Specify a validity period of 2 days and a renewal period of 1 day.

Configure DirectAccess with OTP Authentication

Select the Security tab and click Add. Click Object Types and then select Computers and click Ok. Enter the names of each DirectAccess server separated by semicolons and click Check Names. Click Ok when finished. For each DirectAccess server, grant Read, Enroll, and Autoenroll permissions. Select Authenticated Users and remove any permissions other than Read. Select Domain Computers and remove the Enroll permission. Select Domain Admins and grant Full Control permission. Do the same for Enterprise Admins.

Configure DirectAccess with OTP Authentication

Select the Subject Name tab and choose the option to Build from this Active Directory information. Select DNS name in the Subject name format drop-down list and confirm that DNS name is checked under Include this information in alternate subject name.

Configure DirectAccess with OTP Authentication

Select the Extensions tab, highlight Application Policies and click Edit.

Configure DirectAccess with OTP Authentication

Remove all existing application policies and then click Add and then New. Provide a descriptive name for the new application policy and enter 1.3.6.1.4.1.311.81.1.1 for the Object Identifier. Click Ok for all remaining dialog boxes.

Configure DirectAccess with OTP Authentication

OTP Certificate Template

In the Certificate Templates Console, right-click the Smartcard Logon certificate template and choose Duplicate Template. On the Compatibility tab, select Windows Server 2012 R2 for the Certification Authority and Windows 8.1/Windows Server 2012 R2 for the Certificate recipient.

Configure DirectAccess with OTP Authentication

Select the General tab and provide a descriptive name for the Template Display Name. Specify a validity period of 1 hour and a renewal period of 0 hours.

Configure DirectAccess with OTP Authentication

Note: It is not possible to set the validity period to hours on a Windows Server 2003 Certificate Authority (CA). As a workaround, use the Certificate Templates snap-in on another system running Windows 7/Windows Server 2008 R2 or later. Also, if the CA is running Windows Server 2008 R2, the template must be configured to use a Renewal Period of 1 or 2 hours and a Validity Period that is longer but no more than 4 hours.

Select the Security tab, then highlight Authenticated Users and grant Read and Enroll permissions. Select Domain Admins and grant Full Control permission. Do the same for Enterprise Admins.

Configure DirectAccess with OTP Authentication

Select the Subject Name tab and choose the option to Build from this Active Directory information. Select Fully distinguished name in the Subject name format drop-down list and confirm that User principal name (UPN) is checked under Include this information in alternate subject name.

Configure DirectAccess with OTP Authentication

Select the Server tab and choose the option Do not store certificates and requests in the CA database. Clear the checkbox next to Do not include revocation information issued in certificates.

Configure DirectAccess with OTP Authentication

Select the Issuance Requirements tab and set the value for This number of authorized signatures to 1. Confirm that Application Policy is selected from the Policy type required in signature drop-down list and choose the OTP certificate request signing template created previously.

Configure DirectAccess with OTP Authentication

Select the Extensions tab, highlight Application Policies and click Edit. Highlight Client Authentication and click Remove. Ensure that the only application policy listed is Smart Card Logon.

Configure DirectAccess with OTP Authentication

Certificate Authority Configuration

In the Certificate Authority management console, right-click Certificate Templates, choose New, and then Certificate Template to Issue. Highlight both of the certificate templates created previously and click Ok.

Configure DirectAccess with OTP Authentication

Open an elevated command prompt and enter the following command:

certutil.exe -setreg dbflags +DBFLAGS_ENABLEVOLATILEREQUESTS

Configure DirectAccess with OTP Authentication

Restart the Certificate Authority service by right-clicking the CA in the Certificate Authority management console and choosing All Tasks and then Stop Service. Once complete, repeat these steps and choose Start Service.

DirectAccess Server Configuration

Configuring the DirectAccess server to use OTP for authentication is somewhat challenging. As of this writing, the GUI is broken and will raise an error message complaining that no CA servers can be detected, despite the fact they are online.

No CA servers can be detected, and OTP cannot be configured. Ensure that
servers added to the list are available on each domain controller in the
corporate network.

Configure DirectAccess with OTP Authentication

To work around this issue, configure DirectAccess OTP authentication using PowerShell. Before proceeding, collect the names of the certificate templates you created previously, along with the RADIUS sever hostname and shared secret. In addition be sure to add the CA sever(s) to the DirectAccess management servers as outlined below.

To configure DirectAccess OTP, open an elevated PowerShell window and enter the following commands:

# Add CA server to DirectAccess Management Servers

Add-DAMgmtServer –MgmtServer <CA_Server_Name>

# Enable and Configure DirectAccess OTP

$ca = "<CA_Server_Name>\<CA_Name>"
$template = "<Template Name>"
$signingtemplate = "<Signing Template Name>"
$radius = "<RADIUS_Server_Name>"
$secret = "<Shared_Secret>"

Set-DAServer -UserAuthentication TwoFactor

Enable-DAOtpAuthentication -CAServer $ca -CertificateTemplateName $template
-RadiusServer $radius -SharedSecret $secret
-SigningCertificateTemplateName $signingtemplate

Configure DirectAccess with OTP Authentication

Note: Although the initial configuration of DirectAccess OTP is not possible with the GUI, subsequent OTP settings can be managed in the GUI. For example, you can still use the GUI to add or remove RADIUS servers and manage OTP exemptions. However, adding or removing CA servers or changing certificate templates will still have to be done using PowerShell.

DirectAccess OTP Client Experience

When a DirectAccess client is outside of the corporate network and has established DirectAccess connectivity, users can log on to their machine and access their desktop, but they will not be able to access corporate resources without first providing their OTP. The status indicator for the DirectAccess connection will indicate that action is needed. Clicking on Workplace Connection will indicate that credentials are needed. Clicking Continue will prompt the user to Press Ctrl+Alt+Delete where they will be prompted for their OTP.

Configure DirectAccess with OTP Authentication

Summary

Using dynamic, one-time passwords is an effective way to provide the highest level of assurance for remote DirectAccess clients. It does come with some potential drawbacks, so be sure to consider those before implementing OTP.

Configure F5 BIG-IP for DirectAccess NLS

Recently I wrote about the Network Location Server (NLS) and its importance for DirectAccess deployments. As I described previously, the NLS is nothing more than a web server with an SSL certificate installed. It should also be made highly available to prevent potential service disruption caused by planned or unplanned NLS server downtime. Any web server can serve as the NLS. In addition, if you have the F5 BIG-IP Local Traffic Manager (LTM) in your environment, you can easily configure the LTM to serve as the NLS.

To accomplish this, import the SSL certificate for the NLS and create an SSL client profile using its certificate and private key. Next, create a new iRule that contains the following code.

When HTTP_REQUEST {
HTTP::respond 200
}

Configure F5 BGIP for DirectAccess NLS

Finally, create a new virtual server listening on TCP port 443 and assign this iRule as a resource for the virtual server. Once NLS reachability has been verified, update the DirectAccess configuration using the Remote Access Management console or the Set-DANetworkLocationServer PowerShell cmdlet.

TechMentor 2015 DirectAccess Deep Dive Training Session

I’m excited to announce that I’ll once again be participating in this year’s TechMentor conference in Redmond, WA! The event takes place August 3-7, 2015 and will be held on the Microsoft campus in building 33. This is a great event at an incredible venue! I’ll be delivering a 3 hour Windows Server 2012 R2 DirectAccess deep drive technical training session on Thursday, August 6. The conference covers a wide range of topics from many noted industry experts like Don Jones, Greg Shields, Jeff Hicks, Orin Thomas, and many more. Don’t miss out. Register today and use priority code TMRSK05 to save $500!

TechMentor Conference 2014

DirectAccess Network Location Server Guidance

Introduction

The Network Location Server (NLS) is a critical component in a DirectAccess deployment. The NLS is used by DirectAccess clients to determine if they are inside or outside of the corporate network. If a DirectAccess client can connect to the NLS, it must be inside the corporate network. If it cannot, it must be outside of the corporate network. It is for this reason that the NLS must not be reachable from the public Internet. A client configured for DirectAccess will probe the NLS when it first starts, and on subsequent network interface status changes.

What is the NLS?

The NLS itself is nothing more than a web server with an SSL certificate installed. Beginning with Windows Server 2012, the NLS can be collocated on the DirectAccess server itself. Although there may be scenarios in which this is acceptable, it is generally recommended that NLS be configured on a server dedicated to this role.

NLS Configuration

Any web server can be used, including IIS, Apache, Nginx, Lighttpd, and others. You can also use an Application Delivery Controller (ADC) like the F5 BIG-IP Local Traffic Manager (LTM), as described here. The web server must have a valid SSL certificate installed that includes a subject name that matches the NLS FQDN (e.g. nls.corp.example.com). The DNS record for the NLS must configured using an A host record. A CNAME DNS entry will not work. In addition, the NLS must also respond to ICMP echo requests.

DirectAccess Network Location Server Guidance

DirectAccess Network Location Server Guidance

The certificate can be issued by an internal PKI or a public third-party Certificate Authority (CA). A self-signed certificate can be used if the certificate is distributed to all DirectAccess clients and servers, but this is not advisable. To avoid possible service disruptions, the NLS should be made highly available by deploying at least two NLS in a load balanced configuration.

What Happens if the NLS is Offline?

If the NLS is offline for any reason, remote DirectAccess clients will be unaffected. However, DirectAccess clients on the internal network will mistakenly believe they are outside of the corporate network and attempt to establish a DirectAccess connection. If the DirectAccess server is not accessible from the internal network, the client will be unable to connect to any local network resources by name until the NLS is brought online or other actions are taken.

Collocation Issues

As mentioned previously, it is possible in some scenarios to collocate the NLS on the DirectAccess server. This is probably acceptable for proof-of-concept deployments, but any production deployment should have the NLS configured on a server dedicated to this role. If the NLS is located on the DirectAccess server and the server is offline for any reason, DirectAccess clients on the internal network will be unable to access local resources by name until the DirectAccess server is back online.

Don’t Use Existing Web Application Servers

Occasionally I will encounter a scenario in which an administrator who wants to avoid implementing additional infrastructure will use an existing internal web application server for the NLS, such as a SharePoint server. Although this will work, it quickly becomes an issue when remote DirectAccess clients need to access the server. Since the NLS is not resolvable or reachable externally, connectivity will fail, preventing DirectAccess clients from reaching the internal application.

Summary

The NLS is a vitally important piece of the DirectAccess architecture. DirectAccess clients use the NLS to determine their location, and if the service is unavailable for any reason (planned or unplanned) internal DirectAccess clients will be negatively affected. The NLS isn’t necessarily complicated, as it is nothing more than a web server with an SSL certificate installed. However, don’t overlook the importance of this service, and make sure it is highly available to avoid any potential network connectivity issues.

DirectAccess Deployment Guide for Kemp LoadMaster Load Balancers

DirectAccess Deployment Guide for Kemp LoadMaster Load BalancersA few months ago I had the opportunity to work with the folks at Kemp Technologies to document the use of their LoadMaster load balancers for Windows Server 2012 R2 DirectAccess deployments. DirectAccess has several critical single points of failure which can benefit from the use of a load balancer. Typically Windows Network Load Balancing (NLB) is used in these scenarios, but NLB suffers from some serious limitations and lacks essential capabilities required to fully address these requirements. The use of an external third-party load balancer can provide better load distribution and more granular traffic control, while at the same time improving availability with intelligent service health checks.

Working with the Kemp LoadMaster was a great experience. Installation was quick and simple, and their web-based management console is intuitive and easy to use. The LoadMaster includes essential features that are required for load balancing DirectAccess servers, and advanced capabilities that can be leveraged to enhance geographic redundancy for multisite deployments.

Kemp offers the widest platform coverage with their solutions, including dedicated hardware appliances, virtual appliances for multiple hypervisors including Hyper-V, cloud-based including Microsoft Azure, as well as bare metal support for installation on your own hardware. You can download a fully functional free trial here.

DirectAccess Deployment Guide for Kemp LoadMaster Load Balancers

You can view and download the Windows Server 2012 R2 DirectAccess Deployment Guide for the Kemp LoadMaster load balancing solution here.

Disable 6to4 IPv6 Transition Protocol for DirectAccess Clients

Introduction

DirectAccess client to server connections are established exclusively over IPv6. To allow for this communication to take place over the public IPv4 Internet, DirectAccess uses IPv6 transition protocols – 6to4, Teredo, and IP-HTTPS – to tunnel IPv6 communication over IPv4. 6to4 is supported when the DirectAccess server is edge facing with a public IPv4 address assigned to its external network interface. Two consecutive public IPv4 addresses are required to support Teredo. IP-HTTPS is used in all scenarios, and exclusively when the DirectAccess server is located in a perimeter or DMZ network behind a NAT device.

6to4 and Teredo Advantages

Not all IPv6 transition protocols are created equal. For Windows 7 clients, 6to4 and Teredo provide significant performance advantages when compared to IP-HTTPS (Windows 8.x clients can use null encryption for IP-HTTPS, which eliminates this performance advantage). 6to4 and Teredo offer nearly identical performance, but 6to4 suffers from some unique challenges and should be disabled by default for all DirectAccess deployments.

Note: IP-HTTPS null encryption is disabled for all clients when client-based remote access VPN or one-time password (OTP) authentication is configured on the DirectAccess server, which can impact performance for Windows 8.x clients using IP-HTTPS.

Unreliable Fallback

The 6to4 IPv6 transition protocol is used when a DirectAccess client has a public IPv4 address assigned to its network interface. 6to4 uses IP protocol 41 for transport, and does not work when the client is behind a NAT. If outbound IP protocol 41 is blocked (a common scenario) then the client should fallback to Teredo or IP-HTTPS. In my experience this doesn’t always happen. In fact, the protocol fallback fails with enough regularity that it is the primary reason I recommend disabling it by default.

Active Directory IP Subnet Assignment

6to4 is also problematic when it comes to configuring Active Directory IP subnets for clients in a multisite DirectAccess deployment. 6to4 addresses begin with the 2002::/16 prefix followed by the IPv4 address of the client represented in hexadecimal using the form WWXX:YYZZ::WWXX:YYZZ. For example, if the DirectAccess client’s public IPv4 address is 198.51.100.83, its 6to4 address would be 2002:c633:6453::c633:6453. Since this IPv6 address is created using only the client’s IPv4 address, there is no way to associate the client to a specific entry point. The administrator is left with assigning the 2002::/16 prefix to the most centrally located AD site. This will undoubtedly result in some DirectAccess clients using domain controllers that are not ideal, which will ultimately lead to slow log on times and mapped drive failures.

Summary

In some deployment scenarios, 6to4 and Teredo offer performance advantages when compared to IP-HTTPS. Performance is identical for both 6to4 and Teredo, and considering the challenges that 6to4 poses, it should be disabled by default for DirectAccess deployments. This eliminates the possibility of associated connectivity issues, while still allowing DirectAccess clients to use the Teredo IPv6 transition protocol and not incur any performance penalty. Details about disabling IPv6 transition protocols can be found here.

DirectAccess and Windows 10 Technical Preview Build 9926

Microsoft recently announced the availability of build 9926 of Windows 10 Technical Preview. This new update includes changes to the user interface that make it easier to view DirectAccess connection status and properties. In this latest build, using the Window Key + I keystroke combination now brings up the Settings menu.

DirectAccess and Windows 10 Technical Preview Build 9926

Figure 1 – Settings Window

To view the DirectAccess connection status, click Network & Internet and then click Show available connections.

DirectAccess and Windows 10 Technical Preview Build 9926

Figure 2 – Network & Internet (Show Available Connections)

Here you’ll find status information for all network connections including DirectAccess. Right-clicking the Workplace Connection will allow the user to disconnect their session, if that option is enabled on the DirectAccess server.

DirectAccess and Windows 10 Technical Preview Build 9926

Figure 3 – DirectAccess Connectivity Status Indicator

Selecting the DirectAccess submenu reveals detailed information about DirectAccess connectivity, including current entry point connection and optional entry point selection, if manual entry point selection is enabled on the DirectAccess server.

DirectAccess and Windows 10 Technical Preview Build 9926

Figure 4 – Network & Internet (DirectAccess Advanced Connection Properties)

Active Directory IP Subnets for DirectAccess Clients

Introduction

When deploying Windows Server 2012 R2 DirectAccess I’m often asked which Active Directory (AD) site a client is associated with when it establishes DirectAccess connectivity. The answer depends on the client’s operating system. Windows 8.x and later clients automatically associate themselves with the site to which the DirectAccess server they are connected to belongs. Windows 7 clients lack this capability, and depending on current AD configuration, Windows 7 clients may associate with an incorrect site. This can lead to potential problems such as slow logon times and mapped drive failures. To address this issue it is important to configure IP subnets in AD for DirectAccess clients to eliminate any potential problems. In this article I’ll demonstrate how to create IP subnets in AD and how to identify IPv6 subnets used by DirectAccess clients.

Active Directory IP Subnets

Configuring IP subnets in AD is relatively straightforward. In the Active Directory Sites and Services management console, right-click Subnets and choose New Subnet. Enter the IP subnet prefix and select the AD site where the DirectAccess server for this subnet resides.

Active Directory IP Subnets for DirectAccess Clients

IPv6 Subnets for DirectAccess Clients

To configure AD IP subnets for DirectAccess clients, it will be necessary to identify all potential IP subnets that may be in use. IP subnets used by DirectAccess clients depend on the IPv6 transition protocols supported by the DirectAccess configuration. DirectAccess supports 6to4, Teredo, and IP-HTTPS for client to server communication, and the Intrasite Automatic Tunnel Addressing Protocol (ISATAP) for manage-out connectivity. Any or all of these protocols may be used for a particular DirectAccess configuration.

  • 6to4 – Supported if the DirectAccess server is edge-facing with a public IPv4 address assigned to its external network interface.
  • Teredo – Supported if the DirectAccess server is edge-facing with two consecutive public IPv4 addresses assigned to its external network interface.
  • IP-HTTPS – Supported in all deployment scenarios, and is used exclusively if the DirectAccess server is located behind a NAT device in a perimeter or DMZ network.
  • ISATAP – Optionally used when manage out is enabled and configured.

IP subnets should be configured in AD for all IPv6 transition protocols supported for the DirectAccess deployment.

Identify the 6to4 IPv6 Subnet

Note: Information for the 6to4 protocol is provided here for completeness. However, it is generally recommended that 6to4 be disabled for DirectAccess deployments, making this configuration unnecessary. I’ll provide more details in an upcoming blog post.

The 6to4 IPv6 transition protocol is only supported when the DirectAccess server is edge-facing with a public IPv4 address assigned to its external network interface. 6to4 IPv6 addresses are assigned using the 2002::/16 prefix. For single site DirectAccess deployments, an administrator should create an IP subnet in AD using this prefix and assign it to the AD site where the DirectAccess server resides. If public IPv4 addressing is used internally and the 6to4 transition protocol has not been disabled, it is essential that more specific IP subnets for internal 6to4 clients also be configured.

6to4 and DirectAccess Multisite Challenges

The 6to4 IPv6 transition protocol presents a challenge for multisite DirectAccess deployments. When a client creates a 6to4 IPv6 address, it appends the 2002::/16 prefix with its public IPv4 address represented in hexadecimal using the form WWXX:YYZZ::WWXX:YYZZ. For example, if the DirectAccess client’s public IPv4 address is 198.51.100.83, its 6to4 address would be 2002:c633:6453::c633:6453. Since this IPv6 address is created using only the client’s IPv4 address, there is no way to associate the client to a specific entry point. This is one of the reasons why 6to4 is not recommended for use in DirectAccess deployments. If you must support the 6to4 IPv6 transition protocol in a multisite configuration, assign the 2002::/16 IP subnet to the most centrally located AD site.

Identify the Teredo IPv6 Subnet

The Teredo IPv6 transition protocol is only supported when the DirectAccess server is edge facing with two consecutive public IPv4 addresses assigned to its external network interface. Teredo IPv6 addresses begin with 2001: followed by the primary public IPv4 address (represented in hexadecimal) of the DirectAccess server. For example, if the DirectAccess server’s primary public IPv4 address is 203.0.113.240, the DirectAccess client will be assigned a Teredo IPv6 address using the 2001:cb00:71f0::/48 prefix. An administrator should create an IP subnet in AD using this prefix and assign it to the AD site where the DirectAccess server resides. For multisite deployments, repeat these steps for each DirectAccess entry point.

Identify the IP-HTTPS IPv6 Subnet

The IP-HTTPS IPv6 transition protocol is supported in all DirectAccess configurations and its IPv6 subnet should always be assigned to an AD site. The IP-HTTPS IPv6 prefix assignment differs between single site and multisite deployments.

Single Site Deployment

For single site deployments, a /64 IPv6 prefix is assigned for DirectAccess clients. To identify this subnet, run the Get-RemoteAccess PowerShell command on the DirectAccess server and locate the value of ClientIPv6Prefix

Active Directory IP Subnets for DirectAccess Clients

Multisite Deployment

For multisite deployments, a /59 IPv6 subnet is assigned to each entry point, and each server within the entry point is assigned a /64 prefix for DirectAccess clients. To identify the IPv6 prefixes for each entry point, highlight DirectAccess and VPN below the Configuration node in the Remote Access Management console, and then select the DirectAccess entry point.

Active Directory IP Subnets for DirectAccess Clients

For edge facing deployments with a public IPv4 address assigned to the external network interface, the IPv6 prefix assigned to DirectAccess clients is from the 2002::/16 globally unique address (GUA) range. If the DirectAccess server is configured using a private IPv4 address with a single network interface or with two network interfaces behind a NAT, the IPv6 prefix assigned to DirectAccess clients will be from the fd00::/8 unique local address (ULA) range. An administrator should create an IP subnet in AD using this prefix and assign it to the AD site where the DirectAccess server resides.

Note: Uninstalling and reinstalling DirectAccess will result in a new IP-HTTPS network ID being created. If these changes are made, be sure to update AD IP subnets accordingly.

Identify the ISATAP IPv6 Subnet

Although this article focuses primarily on the IPv6 subnets used by remote DirectAccess clients, it is also important not to overlook AD IP subnet configuration for internal clients if ISATAP is configured for manage out. IP subnets used by ISATAP clients vary depending on the network configuration of the DirectAccess server.

Edge Deployment

For edge deployments, ISATAP addresses are assigned from the 2002::/16 GUA range. This is appended with the public IPv4 address of the DirectAccess server in hexadecimal using the form WWXX:YYZZ:1:0:5efe and the IPv4 address of the ISTAP client in familiar dotted-decimal notation. For example, if the DirectAccess server’s primary public IPv4 address is 203.0.113.240 and the client’s IP address is 172.16.1.77, the DirectAccess client will be assigned the ISATAP address 2002:cb00:71f0:1:0:5efe:172.16.1.77. The subnet to be created by the administrator in AD will then be 2002:cb00:71f0:1:0:5efe::/96 plus the IPv4 network prefix. For example, if the client’s IP address uses a /24 prefix, the AD IP subnet would be configured using 2002:cb00:71f0:1:0:5efe:172.16.1.0/120. This IP subnet should be assigned to the same site where the corresponding IPv4 subnet is assigned.

Perimeter/DMZ Deployment

For perimeter/DMZ deployments, ISATAP addresses are assigned randomly from the fd00::/8 ULA range and begin with fdXX:XXXX:XXXX:1:0:5efe followed by the IPv4 address of the ISTAP client in dotted-decimal notation. For example, if the DirectAccess client’s IP address is 172.16.1.77, its ISATAP address might look like fdca:3ce5:b0a:1:0:5efe:172.16.1.77. The subnet to be created by the administrator in AD will then be fdca:3ce5:b0a:1:0:5efe::/96 plus the IPv4 network prefix. If the clients’ IP address uses a /24 prefix, the AD IP subnet would be configured using fdca:3ce5:b0a:1:0:5efe:172.16.1.0/120. This IP subnet should be assigned to the same site where the corresponding IPv4 subnet is assigned.

Summary

The configuration of Active Directory IP subnets for DirectAccess clients is an often overlooked aspect of DirectAccess deployments. Proper IP subnet mapping to AD sites is critical, especially for large enterprise deployments with complex networks spanning multiple physical locations. It ensures that Windows 7 DirectAccess clients communicate with the closest AD domain controller when they establish a DirectAccess connection, which can eliminate potential issues. In addition, it is recommended to disable 6to4 for DirectAccess clients to avoid the pitfalls that come with the use of this IPv6 transition protocol. Also, don’t forget to configure IP subnets for any internal clients that use ISATAP for manage out.

Forwarding is Disabled on the DirectAccess Teredo Server

Recently while working with a customer to configure Windows Server 2012 R2 DirectAccess I encountered an issue with Teredo failing after enabling multisite. The remote access management console reported the following error:

Teredo: Not working properly
Error: Forwarding is disabled on the Teredo server.

Forwarding is Disabled on the DirectAccess Teredo Server

The resolution is simple enough. Enable forwarding on the Teredo interface! To do this we’ll need to identity the interface index of the Teredo Tunneling Pseudo-Interface and then enable forwarding using netsh.exe. Open an elevated command prompt and issue the following command:

netsh interface ipv6 show interface

Forwarding is Disabled on the DirectAccess Teredo Server

Make a note of the Teredo tunneling interface index and then enable forwarding on this interface by issuing the following command:

netsh interface ipv6 set interface  forwarding=enabled

Forwarding is Disabled on the DirectAccess Teredo Server

DirectAccess Configuration Load Error after Enabling NLB in Hyper-V

When the Windows Server 2012 R2 DirectAccess server is deployed on a virtual machine running in Microsoft Hyper-V, a complete loss of network connectivity immediately after enabling Network Load Balancing (NLB) may occur. In addition, the Remote Access Management console may report the following error .

Configuration Load Error
Settings for <da_hostname> cannot be retrieved.
Domain controller <dc_hostname> cannot be reached for localhost.
Try to reload the configuration.

DirectAccess Configuration Load Error after Enabling NLB in Hyper-V

This issue may be caused by incorrect virtual network adapter settings on the Hyper-V host. To resolve this issue, open the Hyper-V management console, right-click the DirectAccess guest virtual machine and choose Settings. Expand the virtual network adapter and select Advanced Features, then select the option to Enable MAC address spoofing. Repeat these steps for each virtual network adapter assigned to the DirectAccess server virtual machine. Apply the settings and restart the DirectAccess server.

DirectAccess Configuration Load Error after Enabling NLB in Hyper-V
